Product Details
Place of Origin: Shenzhen Guangdong China
Brand Name: BOZEX
Certification: DIN, ISO, ANSI, GB, JIS
Model Number: BZX.S020704-M6-50
Payment & Shipping Terms
Minimum Order Quantity: 1000pcs
Packaging Details: 1000pcs/ box box size: 20cm*20cm*10cm
Delivery Time: 5-8working days
Payment Terms: T/T, L/C
Supply Ability: 50Million pcs per day
Name: |
M6 Stainless Steel Flat Head Screws PVC Slotted Flat Head Screws |
Material: |
PVC |
Finish Color: |
Green, White |
Function: |
Lamps, Furniture, Industry Machine |
Length: |
3 Mm To 50mm |
Thread Type: |
Head, Pan Head, Flange Etc |
Packaging: |
Cartons+plastic Bags, Inner Packing By Plastic Bag; Outer Packing By Carton Box |
Sample: |
Avaliable (shipping Costs Needed) |
Name: |
M6 Stainless Steel Flat Head Screws PVC Slotted Flat Head Screws |
Material: |
PVC |
Finish Color: |
Green, White |
Function: |
Lamps, Furniture, Industry Machine |
Length: |
3 Mm To 50mm |
Thread Type: |
Head, Pan Head, Flange Etc |
Packaging: |
Cartons+plastic Bags, Inner Packing By Plastic Bag; Outer Packing By Carton Box |
Sample: |
Avaliable (shipping Costs Needed) |
M6 Stainless Steel Flat Head Screws PVC Slotted Flat Head Screws
Product Details:
Product Name: White PVC Slotted Flat Head Screws
Original Material: PVC Material
Screw Size: M2, M3, M4, M5, M6, M8, M10 Screw Length: 3 mm to 35mm
Trade Term: FOB, EXW, CIF
PVC Slotted Flat Head Screws Specification:
PVC Slotted Flat Head Screws no need to drill and tap; self tapping screws are pointed, so that they can tap; ordinary screws are flat heads and have the same thickness. Self tapping The screw means: the drilled hole is a hole that does not need to be tapped. The screw used is different from the general one. The tip is pointed and the pitch is relatively large. It is a bit like a chipless tap. It can be directly screwed in without tapping. Metal This method is usually used with plastics.
The difference between flat head screws and countersunk head screws:
One: The contact surface is different, the contact surface of the flat head screw and the workpiece is the bit plane, and the countersunk screw is the bit cone;
Second: the force is different, the force of the grub screw is larger, and the force of the countersunk screw is smaller;
Third: the combination is different, flat head screws can be used in combination with this flat washer, and countersunk head screws can only be used in combination with tapered washer;
Fourth: The use method is different. The flat head screw can go deep into the counterbore or exposed to the outside, but the countersunk head screw is generally only inside the counterbore.
PP Slotted Flat Head Screws Parameters and Drawing
| Size | Code | Dia. | Heat Ht. | Lg. |
| M1.4 x 3 | BZX.S020704-M1.4-3 | 5.5 | 1.65 | 3 |
| M1.4 x 3.5 | BZX.S020704-M1.4-3.5 | 5.5 | 1.65 | 3.5 |
| M1.4 x 4 | BZX.S020704-M1.4-4 | 5.5 | 1.65 | 4 |
| M1.4 x 4.5 | BZX.S020704-M1.4-4.5 | 5.5 | 1.65 | 4.5 |
| M1.4 x 5 | BZX.S020704-M1.4-5 | 5.5 | 1.65 | 5 |
| M1.4 x 6 | BZX.S020704-M1.4-6 | 5.5 | 1.65 | 6 |
| M1.7 x 4 | BZX.S020704-M1.7-4 | 5.5 | 1.65 | 4 |
| M1.7 x 5 | BZX.S020704-M1.7-5 | 5.5 | 1.65 | 5 |
| M1.7 x 6 | BZX.S020704-M1.7-6 | 5.5 | 1.65 | 6 |
| M2.0 x 3 | BZX.S020704-M2.0-3 | 3.8 | 1.2 | 3 |
| M2.0 x 4 | BZX.S020704-M2.0-4 | 3.8 | 1.2 | 4 |
| M2.0 x 5 | BZX.S020704-M2.0-5 | 3.8 | 1.2 | 5 |
| M2.0 x 6 | BZX.S020704-M2.0-6 | 3.8 | 1.2 | 6 |
| M2.0 x 7 | BZX.S020704-M2.0-7 | 3.8 | 1.2 | 7 |
| M2.0 x 8 | BZX.S020704-M2.0-8 | 3.8 | 1.2 | 8 |
| M2.0 x 10 | BZX.S020704-M2.0-10 | 3.8 | 1.2 | 10 |
| M2.0 x 12 | BZX.S020704-M2.0-12 | 3.8 | 1.2 | 12 |
| M2.0 x 14 | BZX.S020704-M2.0-14 | 3.8 | 1.2 | 14 |
| M2.0 x 16 | BZX.S020704-M2.0-16 | 3.8 | 1.2 | 16 |
| M2.0 x 18 | BZX.S020704-M2.0-18 | 3.8 | 1.2 | 18 |
| M2.0 x 20 | BZX.S020704-M2.0-20 | 3.8 | 1.2 | 20 |
| M3 x 4 | BZX.S020704-M3-4 | 5.5 | 1.65 | 4 |
| M3 x 5 | BZX.S020704-M3-5 | 5.5 | 1.65 | 5 |
| M3 x 6 | BZX.S020704-M3-6 | 5.5 | 1.65 | 6 |
| M3 x 7 | BZX.S020704-M3-7 | 5.5 | 1.65 | 7 |
| M3 x 8 | BZX.S020704-M3-8 | 5.5 | 1.65 | 8 |
| M3 x 10 | BZX.S020704-M3-10 | 5.5 | 1.65 | 10 |
| M3 x 30 | BZX.S020704-M3-30 | 5.5 | 1.65 | 30 |
| M3 x 35 | BZX.S020704-M3-35 | 5.5 | 1.65 | 35 |
| M4 x 5 | BZX.S020704-M4-5 | 8.4 | 2.7 | 5 |
| M4 x 6 | BZX.S020704-M4-6 | 8.4 | 2.7 | 6 |
| M4 x 8 | BZX.S020704-M4-8 | 8.4 | 2.7 | 8 |
| M6 x 10 | BZX.S020704-M6-10 | 11.3 | 3.3 | 10 |
| M6 x 20 | BZX.S020704-M6-20 | 11.3 | 3.3 | 20 |
| M6 x 30 | BZX.S020704-M6-30 | 11.3 | 3.3 | |
| M6x 50 | BZX.S020704-M6-50 | 11.3 | 3.3 | 35 |
